34 Programming Guide
Refer to the Installer Quick Menu on page 65 for alternate PGM programming.
Programmable Output Options
48 = Special (Partition 1 only)
00 = System power up
01 = Reporting test
02 = Software log on
03 = Software log off
04 = Installer in programming mode
05 = Installer exited programming mode
06 = Maintenance in programming mode
07 = Maintenance exited programming mode
08 = Closing delinquency delay elapsed
99 = Any special event
49 = Low battery on zone 01 to 32 = Zone number
99 = Any zone number
50 = Low battery on zone restore
51 = Zone supervision trouble
52 = Zone supervision restore
53 = Wireless module supervision trouble (Partition 1 only)
54 = Wireless module supervision restore (Partition 1 only)
55 = Wireless module tamper trouble (Partition 1 only)
56 = Wireless module tamper restore (Partition 1 only)
01 to 16 = Output
17 to 18 = Wireless repeater
19 to 22 = Wireless keypad
27 to 30 = Wireless siren
57 = Non-medical alarm (paramedic)
01 to 32 = User number
99 = Any user number
58 = Zone forced 01 to 32 = Zone number
99 = Any zone number
59 = Zone included
64 = System Status*
00 = Follow Arm LED status**:
1. PGM pulse fast in alarm
2. PGM pulse fast in exit delay below 10 sec.
3. PGM pulse slow in exit delay over 10 sec.
4. PGM steady ON if armed
5. PGM OFF if disarmed
*On-board PGMs only
** This event can be assigned to any partition. If assigned to both
partitions, the PGM event will follow the priority of the list above,
with #1 being the highest priority.
PGM 1
[261]
PGM 2
[262]
PGM 3
[263]
PGM 4
[264]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec, On=Min)
[2] PGM State (Off=N.O., On=N.C.)
[3]* PGM Supervision
[4] PGM Activation Mode (Off=Steady,
On=Pulse)
[5] PGM Pulse once every 30 seconds if armed
[6] PGM Pulse on any alarm
[7] PGM Pulse on any alarm
(OFF= Partition 1, On= Partition 2)
[8] N/A N/A N/A N/A N/A N/A N/A N/A N/A
Event Group # Sub-group #
