Paradox Spectra SP4000 Programming Guide

Magellan / Spectra SP 35
Programmable Output Delays
* To change the base time (min. or sec.), refer to Programmable Output Options on page 34.
PGM 5
[265]
PGM 6
[266]
PGM 7
[267]
PGM 8
[268]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec., On=Min.) 







[2] PGM State (Off=N.O., On= N.C.) 







[3]* PGM Supervision








[4] PGM Activation Mode (Off=Steady,
ON=Pulse)








[5] PGM Pulse once every 30 seconds if armed 







[6] PGM Pulse on any alarm 







[7] PGM Pulse on any alarm
(OFF= Partition 1, On= Partition 2)








[8] N/A N/A N/A N/A N/A N/A N/A N/A N/A
PGM 9
[269]
PGM 10
[270]
PGM 11
[271]
PGM 12
[272]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec, On=Min) 







[2] PGM State (Off=N.O., On=N.C.) 







[3]* PGM Supervision








[4] PGM Activation Mode (Off=Steady,
On=Pulse)








[5] PGM Pulse once every 30 seconds if armed 







[6] PGM Pulse on any alarm 







[7] PGM Pulse on any alarm
(OFF= Partition 1, On= Partition 2)








[8] N/A N/A N/A N/A N/A N/A N/A N/A N/A
PGM 13
[273]
PGM 14
[274]
PGM 15
[275]
PGM 16
[276]
Option OFF ON OFF ON OFF ON OFF ON
[1] PGM Base Time (Off=Sec, On=Min) 







[2] PGM State (Off=N.O., On=N.C.) 







[3]* PGM Supervision








[4] PGM Activation Mode (Off=Steady,
On=Pulse)








[5] PGM Pulse once every 30 seconds if armed 







[6] PGM Pulse on any alarm 







[7] PGM Pulse on any alarm
(OFF= Partition 1, On= Partition 2)








[8] N/A N/A N/A N/A N/A N/A N/A N/A N/A
* This option does not apply to SP4000 systems.
Section
(000 to 255 x 1
sec./mins.)*
Section
(000 to 255 x
1 sec./mins.)*
(Default = 005)
[281] PGM 1: ___/___/___ [289] PGM 9: ___/___/___
[282] PGM 2: ___/___/___ [290] PGM 10: ___/___/___
[283] PGM 3: ___/___/___ [291] PGM 11: ___/___/___
[284] PGM 4: ___/___/___ [292] PGM 12: ___/___/___
[285] PGM 5: ___/___/___ [293] PGM 13: ___/___/___
[286] PGM 6: ___/___/___ [294] PGM 14: ___/___/___
[287] PGM 7: ___/___/___ [295] PGM 15: ___/___/___
[288] PGM 8: ___/___/___ [296] PGM 16: ___/___/___

Paradox Spectra SP4000 Specifications

General

Partitions	2
User Codes	32
Event Buffer	256 events
StayD Mode	Yes
Expandable via Expansion Modules	Yes
Bus	Yes, 4-wire expansion bus
Battery Backup	12V 7Ah
PGM Outputs	2
