COMSPHERE 3600 Series Data Service Units
3-8 December 1996 3610-A2-GB46-60
Table 3-2
Identity Descriptions
Field Name
Information Displayed
Model: 3610 or 3611.
S#: Unit serial number.
DSU SW ver: Software/firmware version residing on DSU or changed using the SW Vers configuration option in
Table 4-4. Refer to Appendix G,
Firmware Version Control Information
.
Netwrk Addr: Using ADp protocol, the ADp network address appears.
Using DPII protocol, the DATAPHONE II address appears.
DSU Rate: Aggregate DDS data rate set for DSU Rate(Kbps)
configuration option. Displays Auto while unit is
locating the data rate. This does not appear for a DBM-
X
.
DBM SW ver: The software/firmware version residing on the DBM. Not valid with V.32 DBM.
DBM Rate: Aggregate data rate set for DBM
Rate(Kbps) configuration option.
DBMtyp:
xxx yy.y z
Type of DBM installed.
xxx
can be:
I
ISDN or DBM-I,
V V.32 or DBM-V,
2wS
2-wire Switched 56 kbps DBM or DBM-D, or
4wS
4-wire Switched 56 kbps DBM or DBM-S
yy.y
indicates the DBM’s maximum data rate.
z
displays P when the Primary Core is set to Yes.
MUX Card: TDM/MCMP. Appears when the MUX circuit card is installed.
MUX App: Currently configured application of TDM/MCMP. Possible values are:
TDM,
MCMP
,
CBrdg (central-site bridge),
EBrdg (extended bridge), and
None (TDM/MCMP circuit card disabled)
MUX SW ver: Software version residing on the TDM/MCMP circuit card.
App Modul:
ASPEN. Allows Single-Port Async/Sync operation.
CISC
or
64CC:
CISC when the Clear Channel with Integrated Secondary Channel chip is present.
64CC when the CISC chip is not present.
LPDA-2. Indicates that the SNA Diagnostic Interface option is installed.
SEQU. Sequoia chip is installed and allows Single-Port Async/Sync operation. Installed in models
3610-A4-xxx or 3611-B4-xxx.
XLOOP. Provides enhanced DDS mode.
