Paradyne COMSPHERE 3610 - Display Screens

COMSPHERE 3600 Series Data Service Units
C-8 December 1996 3610-A2-GB46-60
Digital Test
Access Digital Test from the second-level menu of the
T
est branch. Diagnostics ( Diag ) must be set to None
from the Confg branch first. To set the amount of time
for the Digital T
est ( DT):
. Procedure
1.
Select DSU from the DSU or DBM selection
screen; the DSU T
ests selection screen appears.
PRESS: 4 – DT
2. The DSU Digital T
est selection screen appears.
PRESS: 1 – Start
3. The Port Number selection screen appears.
PRESS: 2 – Prt1
4. The DSU Digital T
est Run T ime input screen
appears. The hhh:mm:ss must be fully populated
as shown below .
Customer ID: ORLANDO2 Model: COMSPHERE 3610
Run T im: 0:00:00
Ctrl–T=T op Menu
Ctrl–U= Up Menu
Ctrl–V=View H/S
ENTER Input Form of (hhh:mm:ss):000:08:00
Ctrl–x = Disconnect
5. Enter the run time for the Digital T est and press
the carriage return <CR>. The following
message appears on the screen: Please wait.
6. The Digital T
est completion screen appears.
For further information on Digital Test, refer to
the Digital Test section of Chapter 3.
Display Screens
Display screens provide configuration information
and results of performance and device-specific tests. All
information is presented on one async terminal screen.
The Health and Status display shown below can be
accessed by:
• Using selection screens and the menu tree path
• Ctrl-V from input screens
• V from all other screens
Customer ID: ORLANDO2 Model: COMSPHERE 3610
H/S: 25:12:45 > 9.6 DDS
T/Ctrl–T=T op Menu
H/S: 21:10:50 > 9.6 NetI
U/Ctrl–U= Up Menu
H/S: > DBM:Disable
V/Ctrl–V=View H/S
Ctrl–x = Disconnect
