Async Terminal Operation
C-53610-A2-GB46-60 December 1996
Screen
T
ypes
There
are three types of async terminal screens:
•
Selection screens
•
Input screens
•
Display screens
Some functions operate the same throughout the
async terminal interface. These functions are the
following:
• To return to the top-level menu from any selection
screen or from anywhere within the menu
hierarchy, enter T (or Ctrl-T
). This is the same as
pressing the
key from the front panel. The t
can be upper or lowercase.
• To return to the previous menu, enter U (or
Ctrl-U
). This is the same as pressing the
key
from the front panel. The u can be upper or
lowercase.
• To view Health and Status, enter V (or Ctrl-V).
See Chapter 3 for Health and Status access using
the front panel. The v can be upper or lowercase.
• T
o end the async terminal session, enter
Ctrl-x.
This logs off the async terminal and returns to the
Password Access Menu screen.
Selection Screens
Selection
screens display the selections available
through the menu tree. After password access, the
T
op-Level Menu screen appears on the async terminal as
shown below
. The unit’s current configuration is
displayed. This
example identifies a Control DSU with
Port 1 operating at the port speed of 9.6 kbps.
To select from the menu, enter the number or letter
that corresponds with your desired selection
(e.g., enter 1 to select the Local branch). No carriage
return <CR> is required.
Customer ID: ORLANDO2 Model: COMSPHERE 3610
LED
Status
Bkup Test
Alarm
Port 1 DSU 9.6 C
1 – Local T/Ctrl–T=T
op Menu
2 – Remote U/Ctrl–U=
Up Menu
V/Ctrl–V=View H/S
PRESS Desired Selection Key:
Ctrl–x = Disconnect
Every
configuration option selection screen presents
Previous as the first choice. From the front panel, the
sequence is Next as the first choice and Prev (Previous)
as the last choice.
The Top-Level Menu screen displays LED status for
Alarm, Backup, and Test for the active core if a
condition exists on the interface. Each status only
appears if the front panel LED is lit or blinking.
When you press
1 – Local, the Second-Level Menu
screen appears. The third line on the screen changes to
Local Mode
and the options follow the menu tree shown
in Appendix A.
Customer ID:
ORLANDO2
Model:
COMSPHERE 3610
Local Mode:
1 – Stat T/Ctrl–T=T
op Menu
2 – Bckup U/Ctrl–U=
Up Menu
3 –
Test V/Ctrl–V=View H/S
4 – Confg
5 – Ctrl
PRESS Desired Selection Key:
Ctrl–x = Disconnect
