COMSPHERE 3600 Series Data Service Units
F-6 December 1996 3610-A2-GB46-60
Table F-5
3600 Hubbing Device Technical Specifications
Specifications
Criteria
APPLICATION Diagnostic interfaces for the Model 3610 DSU
NETWORK MANAGEMENT
INTERFACES
NMS
Two 8-pin modular jacks. The 3600 Hubbing Device has a 6-inch cable that
terminates in a 4-pin modular plug.
PHYSICAL DIMENSIONS
Height
Width (thickness)
Depth
1.9 inches (4.8 cm)
0.9 inches (2.3 cm)
3.4 inches (8.6 cm)
WEIGHT 0.13 pounds (0.06 kg)
Table F-6
Async Terminal Technical Specifications
Specifications
Criteria
APPLICATION ANSI X3.64/VT100 compatibility
Data Rate: 9.6 kbps
8 bits per character, 1 stop bit, no parity
ASYNC TERMINAL CONNECTION
CC-to-DB25 cable One 4-pin modular jack to 25-pin D-subminiature EIA-232 connector.
