PARAMOUNT BED 7B01001000A3 - Specifications

103
3. Specifications
<125 mm single-wheel with resin cover>
Family name A6 Series Bed
Product name Electrical Hospital Bed
Model No.
PA-H 6115
PA-H 6125
PA-H 6115 X*
1)
PA-H 6125 X*
1)
PA-H 6135
PA-H 6145
PA-H 6135 X*
1)
PA-H 6145 X*
1)
PA-H 6215
PA-H 6315
PA-H 6215 X*
1)
PA-H 6315 X*
1)
PA-H 6235
PA-H 6335
PA-H 6235 X*
1)
PA-H 6335 X*
1)
Foot-end side-rail Full length Short length Full length Short length
Dimensions
(cm)
Total length
(min. — max.)
222 to 252 222 to 238 222 to 252 222 to 238
Total width 99
Total height 76.3 [+2, -1] to 121.3 [±1.5]
Mattress deck length 200
Mattress deck
height*
2)
35.8 [+2, -1] to 80.8 [±1.5]
Power cable length E󰀨ectivelength300cm
Product weight
without X-ray
cassette tray
PA-H 6115
PA-H 6125 : 151 kg
PA-H 6135
PA-H 6145 : 149 kg
PA-H 6215
PA-H 6315 : 153 kg
PA-H 6235
PA-H 6335 : 151 kg
with X-ray
cassette tray
PA-H 6115 X
PA-H 6125 X : 156 kg
PA-H 6135 X
PA-H 6145 X : 154 kg
PA-H 6215 X
PA-H 6315 X : 158 kg
PA-H 6235 X
PA-H 6335 X : 156 kg
Maximum user weight 180 kg
Safe working load*
3)
255 kg (2500 N)
Guaranteed
operating
conditions
Temperature 10 to 40°C (when using BED EXIT ALARM: 15 to 30°C)
Humidity 30 to 75% RH
Atmospheric
pressure
620 to 1060 hPa
Transport
and storage
conditions
Temperature -10 to 50°C
Humidity 30 to 90% RH
Atmospheric
pressure
620 to 1060 hPa
Service life
8 years (based on Paramount Bed data)
*Onconditionthatyouperformthespeciedmaintenanceandinspection
and replace the consumable parts (e.g., casters).
Materials
Headboard/
footboard
HDPE resin molding
Bed side-rail HDPE resin molding
Roller bumper EPDM resin molding
Head section
(without X-ray
cassette tray)
HDPE resin molding
Head section
(with X-ray
cassette tray)
Phenolic resin
Hip/knee/leg
sections
HDPE resin molding
Main frame Powder coated steel
Control panel*
4)
PET resin molding
Handheld
controller*
5)
Case: ABS resin molding, Hook: PP resin molding,
Cable: PVC resin molding
Operating principles Link mechanism using expansion and contraction of electric linear actuator
Head up
Inclination angle 0 to 70 ±7°
Required time 30 seconds
Knee up
Inclination angle 0 to 25 ±4°
Required time 7 seconds
Switching angle of
leg section
0 to 10 ±2°
Height up/down
Range 45 cm
Required time*
6)
35 seconds
Trendelenburg/
Reverse
Trendelenburg
Inclination angle - 0 to 15 ±2°
Required time - 16 seconds
5 REFERENCE INFORMATION
