Head end
Head end
80
Oxygen cylinder holder
You can use an oxygen cylinder by attaching an oxygen cylinder holder.
* Oxygen cylinder holder (IC-A83) is not designed for sales in Europe.
Also, it is not distributed in some regions as well where it is not registered as medical equipment.
For details on the sales of oxygen cylinder holder, contact Paramount Bed (see p. 118) or your distributor.
Note!
<PC-5116/IC-A83>
Be sure to use a 500 L oxygen cylinder (with a diameter between 9.5 cm and 11.5 cm).
<PC-5117/PC-5038>
Be sure to use a 1,000 L oxygen cylinder (with a diameter between 14 cm and 15.5 cm).
<IC-A84>
Be sure to use a 1,000 L to 1,500 L oxygen cylinder (with a diameter between 14 cm and 15.5 cm).
Model No.
PC-5116, PC-5117, PC-5038, IC-A83, IC-A84
<PC-5116, PC-5117, IC-A83>
Accessory attachment holes are located at the head end and foot end of the bed in a total of 4 locations.
Note!
Note that the Accessory attachment hole at the foot end moves together when the extension
frame is pulled out.
<PC-5038>
Hook the oxygen cylinder holder in the center of the headboard or footboard.
Oxygen
cylinder
holder
Accessory attachment hole
Hook bracket
Board
PC-5116
To Next Page
