g Function buttons
1 Nurse call auxiliary button (PA-H 631*, PA-H 633*
only (suitable product))
.....Used to make a nurse call.
* The bed and nurse call wall plate need to be
connected with the bed communication cable
(commercially available product).
2 Patient lock-out button
.....Used to block the operation of the patient
control panel and handheld controller
(accessory).
3 Overall lock-out button
.....Used to block all bed operations except for
electric CPR.
4 Night-light button
.....Used to turn the night-light on.
g Status indication
1 Battery status indicator lamp
.....Flashing, etc. indicates the battery status.
(Excluding PA-H 611*, PA-H 612*, PA-H 613*,
PA-H 614*)
2 Low height indicator lamp
.....Minimum height: lamp turns off, otherwise:
lamp turns on
3 Error indicator lamp
.....Fast/slow flashing orange light indicates that
an error has occurred.
