Parker ACR7000 - Dimensions

ACR7000 Stepper User Guide
Control Power Connector Specifications
Description
Specification
Connector Type
Removable screw terminal
Terminals
2
Pitch
0.200 in (5.08 mm)
Wire range
12-24 AWG (0.34-2.5 mm2)
Wire strip length
0.3 in (7-8 mm)
Torque
5 in–lbs nom. (0.5 N-m)
Manufacturer
OnShore or equivalent
OnShore Part Number
OSTTJ020152 (black) OSTTJ025152 (green)
Drive Input Power Connector Specifications
Description
Specification
Connector Type
Removable screw terminal
Terminals
4
Pitch
0.200 in (5.08 mm)
Wire range
12-24 AWG
(0.34-2.5 mm2)
Wire strip length
0.3 in (7-8 mm)
Torque
5 in–lbs nom. (0.5 N-m)
Manufacturer
OnShore or equivalent
OnShore Part Number
OSTTJ040152 (black)
OSTTJ045152 (green)
