Protective Circuits
The ACR7000 drive/controllers include several built-in protective circuits listed below.
Protection Circuit
Short Circuit Motor Input Power
Control Power
Enable Input
Motor Output
Over-Voltage Motor Input Power 30VDC
Control Power 30VDC
Enable Input 30VDC
Over-current Motor Input Power
Control Power
Enable Input
Over-temperature Internal Drive Temperature 130C
WARNING: This product does not incorporate electronic motor overload protection and
does not incorporate motor over-temperature protection.
