Clamping and sawing a wooden workpiece
NOTE
► You can saw wooden workpieces, e.g. skirting boards, with a
max. height of 100 mm and a width of 5 to 30 mm.
♦ Hold down the release buttons 4 and push the tensioning clamp 2
onto the wooden workpiece to position it.
♦ Place the wooden workpiece between the retaining jaw 3 and
the tensioning clamp 2. Make sure that the wooden workpiece is
guided past the guide rods 7 (see fig. 8).
♦ Hold down the release buttons 4 and push the tensioning clamp 2
onto the wooden workpiece. Let go of the release buttons 4 once
the wooden workpiece is clamped (see fig. 8).
♦ Turn the locking button 5 clockwise to fix the wooden workpiece
in place (see fig. 8).
1
1
2
3
Fig. 8 Fig. 9
