PSS 2 B2
GB
│
IE
│
9 ■
♦ Hold the product firmly with one hand on one of the movable
arms 1. In addition, hold onto skirting boards that do not retain a
90° angle after clamping (see fig. 9).
♦ Using the other hand, guide the saw through the guide rods 7
from above (see fig. 10).
♦ Saw through the wooden workpiece.
♦ Turn the locking button 5 anticlockwise to release the wooden
workpiece (see fig. 11).
♦ Remove the wooden workpiece.
Fig. 10 Fig. 11
Cleaning and storage
ATTENTION! PROPERTY DAMAGE!
► Do not use aggressive or abrasive cleaning agents, as these
can damage the surfaces of the product.
♦ Use a soft dry brush to remove the sawdust from the product.
♦ You can also clean the product using a dry cloth.
♦ Store the product in a clean, dry location away from direct sunlight.
IB_380558_PSS2B2_LB8.indb 9 05.04.2022 12:24:37
