46
Flip / Mirror
Image is flipped or mirrored.
Rotate Left / Right
Rotates the image in steps of 90°.
Set ‘File Save ROI’
To save just a part of the recorded image
(region of interest), draw a rectangle with the
mouse. This rectangle is valid for all recorded
images and can be dragged at its edges.
Line Profile
Point the mouse where the line should start
and left-click. Move the mouse to the desired
line end and left-click again. The line may be
stretched, shrunk or moved by grasping its end
point. A Line Diagram opens. The graph in the
length of the line (units: pixel) is displayed
showing the intensity values of the pixels along
the red line.
Crosshairs
Activates centered crosshairs. Size and color
are selectable see chapter 6.9.2 → Options.
To move the crosshairs drag it by mouse.
Reset it to center position by double-click into
center of the crosshairs.
Copy to Clipboard
Copies the actual image to clipboard.
Properties
Displays the current settings for View Mode / Common View Mode
and Image Conversion.
