42
6.9.4 ACQUISITION MENU
Live Preview
Live Preview for quick and easy adjusting and focusing of the
camera. The active window is refreshed. To see another
window, simply click on the window.
Acquire Picture
Only available if Trigger Mode is set to Soft Trigger, see 6.3.1
Acquire Sequence
Starts recording images into the system memory according to Trigger
Mode selection (see 6.3.1). During recording, all camera controls are
locked.
Rec. Memory Settings
This sets the number of images recorded in one sequence. The
maximum is defined by approved RAM size.
Auto Camera RAM Segment Switching (not available)
6.9.5 VIEW MENU
B/W or Color Window
Opens a new View window.
Multi Window
View the images of all active cameras in
consecutive order in one window. It provides
an easy comparison of the views of different
cameras.
Use the same ROI and timing settings for all
cameras.
Only available when using more than one camera and only after a
complete sequence is recorded (Sequence mode) or after buffer is
full for the first time (Ring Buffer mode).
