Pco pixelfly usb - A1 Technical Data; A1.1 Data Sheet

41
A1 TECHNICAL DATA
A1 TECHNICAL DATA
A1.1 DATA SHEET
image sensor
type of sensor
CCD
image sensor
ICX 285L
resolution (h x v)
1392 x 1040 pixel (normal)
800 x 600 (centered)
pixel size (h x v)
6.45 µm x 6.45 µm
sensor format / diagonal
2/3” / 11.14mm
shutter mode
global (snapshot)
MTF
77.5 lp/mm (theoretical)
fullwell capacity
16000 e
-
24000 e
-
(binning)
readout noise
5 - 7 e
-
rms @ 12 MHz (typ)
6 - 8 e
-
rms @ 24 MHz (typ)
dynamic range
2667 : 1 (68 dB)
4000 : 1 (72 dB binning)
quantum efficiency
62% @ peak
spectral range
290 nm .. 1100 nm
dark current
1 e
-
/pixel/s @23°C
DSNU
2 e
-
rms
PRNU
< 1%
camera
frame rate
7.3 / 13.5 fps (12 / 24 MHz normal)
11.7 / 21.6 fps (12 / 24 MHz center)
exposure / shutter time
1 µs .. 60 s
dynamic range A/D
14 bit
A/D conversion factor
1.0 e
-
/ count
1.5 e
-
/ count
pixel scan rate
12 / 24 MHz
pixel data rate
19.5 Mpixel/s
binning
1x1 .. 4x4
non linearity
< 1 %
smear
< 0.002 %
anti-blooming factor
> 400 (standard 100 ms exposure)
> 4 (NIR boost 100 ms exposure)
interframing time
1 µs (optional)
trigger input signals
software / TTL level
trigger output signals
3.3 V LVTTL level
data interface
USB 2.0
general
power supply
9 .. 28 VAC (12 VDC optional)
power consumption
< 4 W
weight
0.25 kg
operating temperature
+10°C .. +45°C
operating humidity range
10% .. 80% (non-condensing)
storing temperature range
-20°C .. +70°C
optical interface
C-mount
CE / FCC certified
yes
Subject to change, please refer to current data sheet available on our website.
