APPENDIX 1A: COMMISSIONING CONFIGURATION RECORD  SHORT MENU
DRIVE NO: _____________ MODEL: _______________
SITUATION: ______________________________________
MOTOR kW: _________ A: __________ V: _______
POLES: _______________ RPM: _________________
RECORD 1 RECORD 2 RECORD 3
DATE __/__/__ __/__/__ __/__/__
BY _________ _________ _________
ADJUSTMENTS
(= default)
10 MTR CUR _________ _________ _________
(= I Inv.)
11 MTR VOLT _________ _________ _________
(= 415V)
12 MTR FR _________ _________ _________
(= 50Hz)
14 BOOST _________ _________ _________
(= 0.0%)
15 ACC1 _________ _________ _________
(= 10.0 Hz/s)
16 DEC1 _________ _________ _________
(= 10.0 Hz/s)
23 FR F1 _________ _________ _________
(= +0.0 Hz)
24 FR F2 _________ _________ _________
(= +60.0 Hz)
42 DEC3 _________ _________ _________
(= 10.0 Hz/s)
