Microdrive Series Instruction Manual
4201-109 Rev I
92
APPENDIX 1B: COMMISSIONING CONFIGURATION RECORD  FULL MENU
DRIVE NO: _____________ MODEL: _______________
SITUATION: ______________________________________
MOTOR kW: _________ A: __________ V: _______
POLES: _______________ RPM: _________________
RECORD 1 RECORD 2
DATE __/__/__ __/__/__
BY _________ _________
ADJUSTMENTS (= default) RECORD 1 RECORD 2
10 MTR CUR (= I Inv.) _________ _________
11 MTR VOLT (= 415V) _________ _________
12 MTR FR (= 50Hz) _________ _________
13 MTR COOL (= 40%) _________ _________
14 BOOST (= 0.0%) _________ _________
15 ACC1 (= 10.0Hz/s) _________ _________
16 DEC1 (= 10.0Hz/s) _________ _________
17 T CONST (Note 1) _________ _________
18 I LIMIT (= 1.2 I Inv.) _________ _________
19 ILT T/O (= NONE) _________ _________
20 ILT SLIP (Note 2) _________ _________
21 MIN FR (= 0.0Hz) _________ _________
22 MAX FR (= 60.0Hz) _________ _________
23 FR F1 (= +0.0Hz) _________ _________
24 FR F2 (= +60.0Hz) _________ _________
25 MIN FLUX (= 100%) _________ _________
26 DC LEVEL (= 0%) _________ _________
27 DC TIME (= 0.0s) _________ _________
28 DC HEAT (= OFF) _________ _________
29 FR ON (= 12.0Hz) _________ _________
30 FR OFF (= 10.0Hz) _________ _________
31 I SENSE (= I Inv.) _________ _________
32 M-FR1 (= +0.0Hz) _________ _________
33 M-FR2 (= +0.0Hz) _________ _________
34 M-FR3 (= +0.0Hz) _________ _________
35 M-FR4 (= +0.0Hz) _________ _________
36 M-FR5 (= +0.0Hz) _________ _________
37 M-FR6 (= +0.0Hz) _________ _________
38 M-FR7 (= +0.0Hz) _________ _________
39 ACC2 (= 10.0Hz/s) _________ _________
40 DEC2 (= 10.0Hz/s) _________ _________
41 BRK FR (= 0.0Hz) _________ _________
42 DEC3 (= 10.0Hz/s) _________ _________
RECORD 1 RECORD 2
43 T GAIN (= 20.0) _________ _________
44 DB TIME (= 10s) _________ _________
45 DB DUTY (= OFF) _________ _________
46 SLIP FR (= 0.0%) _________ _________
47 SKIP1 (= 0.0Hz) _________ _________
48 SKIP2 (= 0.0Hz) _________ _________
49 SK BW (= 0.0Hz) _________ _________
50 COMMS.ADR (= 10) _________ _________
51 BAUDRATE (= OFF) _________ _________
52 VLT SLIP (Note 2) _________ _________
53 DAMPING (Note 2) _________ _________
54 FB RLY (=10.0 Hz) _________ _________
MODES
60 STR MODE (= RAMP) _________ _________
61 STP MODE (= RAMP) _________ _________
62 REGEN (= V-CLAMP) _________ _________
63 KEYBD CONT. (= N) _________ _________
64 REF FR (= V/mA) _________ _________
65 FB SRC (= O/LOOP) _________ _________
66 I/P MODE (= 01) _________ _________
67 O/P RELAY1 (= 00) _________ _________
68 O/P RELAY2 (= 03) _________ _________
69 O/P RELAY3 (= 05) _________ _________
70 ANALOG O/P (= 00) _________ _________
71 REV INHIBIT (= N) _________ _________
72 SWITCH FR (= WW) _________ _________
73 HV LOW TRIP (= N) _________ _________
74 COMMS T/O (= OFF) _________ _________
75 I LIM MODE (= I) _________ _________
76 I LIM SRC (= 00) _________ _________
77 AUTOBOOST (= Y) _________ _________
78 MIN FR RUN (=N) _________ _________
79 MFI INVERT (=N) _________ _________
Note 1: The default value for the time constant is
dependent upon the Microdrive model. For the
UD3, the default time constant is 0.0s. For the
UDi, the default time constant is 0.05s.
Note 2: The default value of these parameters is
dependent upon the Microdrive model. If the
motor rating is considerably smaller than that
of the Microdrive, these values may need
adjustment. Refer to the appropriate section
of this manual for instructions.
