Pearson CE35-T Case - Guard door safety interlocks; Set-up Arm Safety

Guard door safety interlocks - shut down machine operation when doors are
opened.
Set-up Arm Safety:
Crush Hazard! Secure set-up arm before servicing
machine. Arm could fall without warning.
CE35-T Case Erector Operations Manual
3/2/2010 M-CE35T-2c Horiz Mag
12
ytefaS enihcaM
Fig. 1: Guard Door Safety Interlock
Fig. 2: Guard Door Safety Interlock
Fig. 3: Set-up Arm
Set-Up Arm in
up position
Locking Key
