Operation
6.5.13.1 Adjusting the Suntour fork rebound damping
Only applies to pedelecs with this equipment
Figure 120: Example of Suntour rebound screw (1)
The fork sag is adjusted.
1 Turn the rebound screw in a clockwise
direction to the closed position until it stops.
2 Turn the rebound screw slightly in an anti-
clockwise direction.
Adjust the rebound damping in such a way that
the fork rebounds quickly, but without
bottoming out upwards.
Bottoming out refers to when the fork rebounds
too quickly and stops moving abruptly once it
has reached the full rebound distance. You can
hear and feel a slight impact when this
happens.
