MY22P01 - 12_1.0_31.08.2021
160
Cleaning and servicing
7.4.17 Caring for the brake
7.4.17.1 Caring for the brake
Lubricate articulated joints and mechanical
parts which are accessible from outside with a
few drops of spray oil or precision mechanics
oil.
7.4.18 Lubricating the eightpins seat post
tube
Use a 2.5 ml syringe to carefully fill eightpins
Fluid V3 very slowly into the lubricating nipple
on the outer tube.
Figure 148: Lubricating the seat post tube
Notice
Never treat brake levers with degreaser or
penetrating oil spray.
Notice
Fill a maximum of 2.5 ml since otherwise the
reservoir inside will overflow and the oil will
spill into the frame.
