Description
3.4.5.2 SHIMANO hub gear
Only applies to vehicles with this equipment
SHIMANO hub gears feature a twist grip with a
display on the right-hand side of the handlebars.
Figure 48: SHIMANO SL-C30000-7 gear shift, top view
1 Twist grip
2 Gear indicator
The Gear indicator shows the selected gear.
The gear is changed by turning the twist grip.
Figure 49: SHIMANO SL-C30000-7O gear shift
1 Twist grip
2 Gear indicator
3 Gear cable outer sleeve
1
2
3
1
2
