Pegasus Evo CX - Technical Data; Pedelec; Emissions; Bicycle Lighting

MY22P01 - 12_1.0_31.08.2021
60
Description
3.5 Technical data
3.5.1 Pedelec
3.5.2 Emissions
*The safety requirements as per Electromagnetic Compatibility
Directive 2014/30/EU have been met. The pedelec and the
charger can be used in residential areas without restriction.
3.5.3 Bicycle lighting
3.5.4 BOSCH Intuvia on-board computer
3.5.5 USB port
3.5.6 Motor
3.5.6.1 BOSCH Performance Line CX
Power output/system 250 W (0.25 kW)
Shut-off speed 25 km/h
Table 29: Pedelec technical data
A-weighted emission sound
pressure level
< 70 dB(A)
Total vibration level for the hands
and arms
<2.5m/s²
Highest effective value of
weighted acceleration for the
entire body
<0.5m/s²
Table 30: Emissions from the pedelec*
Voltage about 12 V
Maximum output
Front light 17.4 W
Rear light 0.6 W
Table 31: Bicycle lighting
Internal lithium ion battery 3.7 V, 230 mAh
Operating temperature -5… +40 °C
Storage temperature -10… +40 °C
Charging temperature 0… +40 °C
Protection class
(with USB cover closed)
IPx54
Weight about 0.15 kg
Table 32: Technical data for BOSCH Intuvia on-board
computer, BUI255
Charge voltage 5V
Charging current Max. 500 mA
Table 33: USB port technical data
Maximum continuous power 250 W
Max. torque 85 Nm
Nominal voltage 36 V DC
Protection class IP54
Weight 3 kg
Operating temperature -5… +40 °C
Storage temperature -10… +40 °C
Table 34: Technical data for BOSCH Performance Line CX
motor, BDU450CX
