Pegasus Evo CX - Checking the Lighting

MY22P01 - 12_1.0_31.08.2021
169
Cleaning and servicing
7.5.3 Checking the lighting
1 Check the cable connections on the front and
rear lights for damage and corrosion and
ensure they are firmly in position.
 If cable connections are damaged or corroded,
or are not firmly in positioned. take pedelec out
of service. Contact specialist dealer.
2 Switch light on.
3 Check that the front and rear lights come on.
 If the front or rear lights do not come on, take
pedelec out of service. Contact specialist
dealer.
4 Place pedelec 5 m from the wall.
5 Stand the pedelec up straight. Hold the
handlebars straight with both hands. Do not
use the kickstand.
.
Figure 153: Light positioned too high (1), correctly (2) and too low (3)
6 Check the position of the light beam.
 If the light is positioned too high or too low,
adjust riding light (see Section 6.5.14
).
I
II
III
1
2
1
2
1
2
