3.3.5.5 Back-pedal brake
Figure 25: Brake system with a back-pedal brake – example
1 Rear wheel rim brake
2 Handlebars with brake lever
3 Front wheel rim brake
4 Pedal
5 Back-pedal brake
The back-pedal brake stops the rear wheel from
moving by pushing the pedals in the opposite
direction to the direction of travel.
