MY22P01 - 12_1.0_31.08.2021
44
Description
3.3.8.5 Integrated battery
Four different types of pannier rack batteries can
be fitted:
Figure 36: Overview of integrated battery
Figure 37: Integrated battery in detail
1Battery key
2 Retainer guard
3 Securing hook
4 On-off button (battery)
5 Battery level indicator (battery)
6 Battery housing
3.3.8.6 Charger
Each pedelec is supplied with a charger. As a
general rule, any BOSCH charger may be used:
• The 2 A compact charger
• The 4 A standard charger
• The 6 A fast charger
Observe the operating instructions in the
Section 11.4 Documents.
3.3.9 Lighting
When the riding light is activated, the front light
and the rear light are switched on together.
PowerTube
400
PowerTube
500
PowerTube
625
PowerTube
750
(vertical and horizontal)
