MY22P01 - 12_1.0_31.08.2021
144
Operation
6.22.1 Screwing in the quickly adjustable stem
Only applies to pedelecs with this equipment
Screw in the All Up stem to save space when
parking.
1 Open stem clamping lever.
Figure 143: Example of All Up with open stem clamping
lever
2 Pull handlebars into highest possible position.
Figure 144: Example of All Up pulled into highest possible
position
3 Turn handlebars 90° in a clockwise direction.
Figure 145: Example of All Up screwed in
4 Place handlebars at required height.
5 Close stem clamping lever.
