Pendulum CNT-91R User Manual

Specifications
limit 1
Capture & store values inside
limits 1 and 2
Capture & store values outside
limits 1 and 2
Meas. Pacing
Time Range:
2 s - 500 s
Equidistancy:
±(2

s + 0.1% of pacing time)
Mathematics
Functions:
K*X+L, K/X+L, (K*X+L)/M,
(K/X+L)/M and X/M-1
X is current reading. K, L and
M are constants, set via
keyboard or as frozen
reference value (X
0
).
Other Functions
Measuring Time:
20 ns - 1000 s for Period AVG,
Timebase
Reference:
Display Hold:
Frequency and PRF, 20 ns - 2
s for Freq. in Burst; Single cycle
for other meas. functions. Times
>2 s are software controlled w.
reduced resolution and
accuracy.
Internal, external or automatic
Freezes meas. result until a
new measurement is initiated
via Restart.
Digit Blanking:
Removes (blanks) 1 to 13
digits from the calculated result
before displaying it.
Limit Alarm:
Annunciator on display
and/or SRQ via GPIB
Limit Values:
Lower limit (limit 1)
Upper limit (limit 2)
Settings:
Off
Alarm if value > limit 2
Alarm if value < limit 1
Alarm if
limit 1 < value < limit 2
Alarm if value > limit 2 or
value < limit 1
On Alarm:
Stop or Continue
Display:
Numeric:
Numeric + graphic
Current measurement value
+ annunciator for limit alarm
Graphic:
Horizontal line w.
upper/lower limit markers +
current value marker
Stored
Instrument
Setups:
20 complete setups can be
saved and recalled from
internal non-volatile memory;
10 can be user protected
Display
Type & Use:
Graphics screen for menu
control, numerical readout (14
digits) and status info
Resolution:
320 x 97 pixels
Technology:
Monochrome LCD with white
LED backlight
GPIB Interface
Programmable
Functions:
All front panel accessible
functions
Compatibility:
IEEE 488.2-1987,
SCPI 1999
Modes:
Native mode
Agilent compatible mode
8-9
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
