General
Specifications
Environmental Data
Class:
MIL-PRF-28800F,
Class 3
Operat.
Temp:
0 °C to +50 °C
Storage Temp:
-40 °C to +71 °C
Humidity:
5-95 % @ 10-30 °C
5-75 % @ 30-40 °C
5-45 % @ 40-50 °C
Max.
Altitude:
4600 m
Vibration:
Random
and
sinusoidal
per
MIL-PRF-28800F,
Class 3
Shock:
Half-sine 30G per
MIL-PRF-28800F;
bench
handling
Transit
Drop
Test:
Transport
box tested according
to UN-D 1400 drop test program
1.
Heavy-duty
transport case and
soft carrying case tested
according
to MIL-PRF-28800F.
Reliability:
MTBF 30000 h, calculated
Safety:
Designed
and tested for
Measurement Category
I,
Pollution
Degree 2, in
accordance
with EN/IEC
61010-1:2001
and
CAN/CSA-C22.2
No.
61010-1-04
(incl. approval)
EMC:
EN 61326 (1997) A1 (1998),
increased
test levels per EN
50082-2,Group 1, Class B, CE
Power Requirements
Line
Voltage:
90-265 V
RMS
, 45-440 Hz
Power
Consumption:
<40 W
Dimensions & Weight
Width:
% x 19" (210 mm)
Height:
2U (90 mm)
Depth:
395 mm
Weight:
Net 2.7 kg (5.8 lb)
Shipping
appr. 3.5 kg
(7.5 lb)
Ordering
Information
Basic
Model
s
CNT-90XL-27G\
\40G\46G\60G:
27 /40 /46 /60 GHz
Microwave
Frequency
Counter/Analyzer
including
medium stability OCXO
timebase
Included
with
Instrument:
36 months product warranty,
line cord, brochure with
important information;
'getting started' manual,
user's manual, and
programmer's handbook
on
CD;
Certificate
of Calibration.
RF Input
Versions
-27G:
27 GHz Input C
-40G:
40 GHz Input C
-46G:
46 GHz Input C
-60G:
60 GHz Input C
Timebase
Options*
Option
30/90:
Very high stability OCXO
Option
40/90:
Ultrahighstability OCXO
* Option 19/90 Medium Stability OCXO
timebase
is
the standard
oscillator
in all
CNT-90XL
models
Pulsed RF
Option
Option 28: Pulsed RF measurements
Optional
Accessories
Option
22/90:
Rackmount
kit
Option
23/90:
Battery supply unit
Option
27:
Carrying case
Option
27H:
Heavy-duty
hard transport
case
Option
29/90:
TimeView
modulation
domain analysis SW for
CNT-90XL
Option
90/01:
Cal.
certificate
w. protocol;
standard oscillator
Option
90/06:
Cal.
certificate
w. protocol;
oven oscillator
Option
90/00:
Cal.
certificate
w. protocol;
hold-over
frequency
aging/week
Option
95/05:
5 years extended warranty
Printed
Manuals:
GS-90-DE
*
Getting Started
German
GS-90-ENG
*
Getting Started
English
GS-90-FR
*
Getting Started
French
OM-90
*
User’s
Manual
PM-90
*
Programmer’s
Handbook
SM-90
Service
Manual
* Included as PDF-file upon shipment
Specifications
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
8-24
