Pendulum CNT-91R User Manual

Specifications
Interface
Functions:
Max. Meas. Rate
Via GPIB:
To Internal
Memory:
Internal Memory
Size:
Data Output:
SH1, AH1, T6, L4, SR1,
RL1, DC1, DT1, E2
15 k readings/s (block) 650
readings/s (individual) 4 k
readings/s (talk only)
250 k readings/s, 100 k
readings/s w. calibr. on
>3.9 M readings w. calibr.
off
ASCII, IEEE double precision
floating point
USB Interface
Version:
2.0 Full Speed, 12 Mb/s
Protocol:
USBTMC-USB488
TimeView™
This software package is intended for ad-
vanced Modulation Domain analysis and runs
on any 32-bit Windows® system.
■ Data Capture Modes &
Measurement Rate
Effective rate depends on measurement func-
tion and internal data format.
Free-running
Measurement:
250 k readings/s
Repetitive
Up to 100 Msa/s equiv.
Sampling:
sample rate (10 ns between
samples)
Continuous
Yes, from LF to 250 kHz
Single Period:
repetition rate
Waveform
Capture:
Yes
Data Analysis
Measurement data vs time
Features:
Cursor measurements
Distribution histogram FFT
graph w. Hamming, Hanning
and other relevant filters
Smoothing Zoom
Setup, measurement data
archive and printing Zero dead
time ADEV and MADEV vs. 
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
8-54
