Pendulum CNT-91R User Manual

Specifications
4 k readings/s (talk only)
To Internal
250 k readings/s, 100 k
Memory:
readings/s w. calibr. on
Internal Memory
>3.9 M readings w. calibr.
off
Size:
Data Output:
ASCII, IEEE double precision
floating point
USB Interface
Version:
2.0 Full Speed, 12 Mb/s
Protocol:
USBTMC-USB488
TimeView™
This software package is intended for ad-
vanced Modulation Domain analysis and runs
on any 32-bit Windows® system.
■ Data Capture Modes &
Measurement Rate
Effective rate depends on measurement
function and internal data format.
Free-running
Measurement:
250 k readings/s
Repetitive
Up to 100 Msa/s equiv.
Sampling:
sample rate (10 ns between
samples)
Continuous
Yes, from LF to 250 kHz
Single Period:
repetition rate
Waveform
Capture:
Yes
Data Analysis
Measurement data vs time
Features:
Cursor measurements
Distribution histogram
FFT graph w. Hamming,
Hanning and other relevant
filters
Smoothing
Zoom
Setup, measurement data
archive and printing
Zero dead time ADEV and
MADEV vs.

8-39
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020

Pendulum CNT-91R Specifications

General

Brand	Pendulum
Model	CNT-91R
Category	Measuring Instruments
Language	English
