Pendulum CNT-91R User Manual

Specifications
Period A, B Single
Range A, B:
3.3 ns - 1000 s
Resolution:
50 ps rms typical
■ Display:
Main Parameter:
Period
Aux. Parameters:
V
max
, V
min
,
V
p-p
Period A, B Back-to-Back
Range A, B:
4 ns - 500 s
Resolution:
50 ps rms typical
■ Display:
Main Parameter:
Period
Aux. Parameters:
V max, V min,
V
p-p
Ratio A/B, B/A, C/A, C/B
Range:
Freq Range A,B:
Freq Range C:
10
-9
to 10
11
(one-pass
measurem., values < 1 with
reduced resolution)
100 Hz to 400 MHz
Full input C range
■ Display:
Main Parameter:
Ratio
Aux. Parameters:
Freq 1, Freq 2
Time Interval A to B, B to A, A
to A,B to B
Range (normal
calculation):
0 ns to +10
6
s
Range (smart
calculation):
-10
6
to +10
6
s
Resolution
Single Shot:
50 ps rms typical
Input Frequency:
Up to 160 MHz
Min. Pulse Width:
1.6 ns
Smart Calculation:
Smart Time Int. w. 4 time
stamps (2 consecutive Trig A
plus 2 consecutive Trig B) to
determine sign (A before B or A
after B)
■ Display:
Main Parameter:
Time interval
Aux. Parameters:
None
Pulse Width A, B
Range:
2.5 ns - 10
6
s
Input Frequency:
Up to 200 MHz
Modes:
Pos. pulse width or neg.
pulse width
■ Display:
Main Parameter:
Pulse width
Aux. Parameters:
V
max
, V
min
, V
p-p
Rise and Fall Time A, B
Range:
1.5 ns - 1000 s
Input Frequency:
Up to 160 MHz (square
Trigger Levels:
wave)
Default 10% and 90%
Manually adjustable
1.6 ns
Rise or fall time
Min. Pulse Width:
Modes:
Min. Amplitude
100 mVp-p
■ Display:
Main Parameter:
Rise or fall time
Aux. Parameters:
Slew rate, Vmax, V
min
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
8-32

Pendulum CNT-91R Specifications
