Pendulum CNT-91R User Manual

Using the Controls
Default Settings
See page 2-16 to see how the following prepro-
grammed settings are recalled by a few key-
strokes.
PARAMETER
VALUE/SETTING
Input A & B
Trigger Level
AUTO
Trigger Slope
POS
Impedance
1 M 
Attenuator
1x
Coupling
AC
Filter
OFF
Arming
Start
OFF
Start Slope
POS
Start Arm Delay
0
Stop
OFF
Stop Slope
POS
Hold-Off
Hold-Off State
OFF
Hold-Off Time
200 s
Time-Out
Time-Out State
OFF
Time-Out Time
100 ms
Statistics
Statistics
OFF
No. of Samples
100
No. of Bins
20
Pacing State
OFF
Pacing Time
20 ms
Mathematics
Mathematics
OFF
PARAMETER
VALUE/SETTING
Math Constants
K=1, L=0, M=1
Limits
Limit State
OFF
Limit Mode
RANGE
Lower Limit
0
Upper Limit
0
Burst
Sync Delay
400 s
Start Delay
0
Meas. Time
200 s
Freq. Limit
400 MHz
Miscellaneous
Function
FREQA
Smart Frequency
AUTO
Smart Time Interval
OFF
Meas. Time
200 ms
Auto Trig Low Freq
100 Hz
Timebase Reference
AUTO
Blank Digits
0
Interpolator calibration
ON
Output (CNT-91(R))
OFF
2-20
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
