■ Display:
Main Parameter:
Time interval
Aux. Parameters:
None
Pulse Width A, B
Range:
2.5 ns - 10
6
s
Input Frequency:
Up to 200 MHz
Modes:
Pos. pulse width or
neg. pulse width
■ Display:
Main Parameter:
Pulse width
Aux. Parameters:
Vmax, Vmin, V p-p
Rise and Fall Time A, B
Range:
Input Frequency:
Trigger Levels:
Min. Pulse Width:
Modes:
Min. Amplitude
■ Display:
Main Parameter:
Aux. Parameters:
1.5 ns - 1000 s
Up to 160 MHz (square
wave)
Default 10% and 90%
Manually adjustable
1.6 ns
Rise or fall time
100 mVp-p
Rise or fall time
Slew rate, V
max, V min
Phase A Rel. B, B Rel. A
Range:
Resolution:
Input Frequency:
Min. Pulse Width:
■ Display:
Main Parameter:
Aux. Parameters:
-180° to +360°
0.001° to 10 kHz
0.01° to 1 MHz
0.1° to 10 MHz
1° >10 MHz Resolution
can be
improved by
averaging (Statistics)
Up to 160 MHz
1.6 ns
Phase
Freq (prim. channel),
VA/VB (in dB)
Duty Factor A, B
Range:
0.000001 to 0.999999
Input Frequency:
0.1 Hz - 200 MHz
Min. Pulse Width:
2.5 ns
Modes:
Pos. or neg. duty factor
■ Display:
Main Parameter:
Duty factor
Aux. Parameters:
Period, pulse width
Vmax, Vmin, Vp-p A, B
Alternative data within parentheses refer to
input attenuator setting x10.
Range:
Input Frequency:
Mode:
Resolution:
Accuracy (typ.)*:
DC
1 H z - 1k H z
1 kHz - 20 MHz
20 - 100 MHz
100 - 300 MHz
-5 V to +5 V
(-50 V to +50 V)
DC, 1Hz - 300 MHz,
100 Hz - 300 MHz default
(higher LF limit means
higher meas. speed)
Vmax, Vmin, Vp-p*
3 (30) mV
1% ± 15 (150) mV
1% ± 15 (150) mV
3% ± 15 (150) mV
10% ± 15 (150) mV
30% ± 15 (150) mV
* V p-p is calculated as Vmax - V min, which
means that the maximum absolute error will
be ±30 (300) mV.
■ Display:
Main Parameter:
Aux Parameters:
Power C
Range:
Power:
Frequency:
Resolution:
Accuracy:
Acquisition:
Acquisition Time:
Aux. Parameter:
Vmax or Vmin or V p-p
Vmin, Vp-p or Vmax,
Vp-p or V
min
, V
max
-35 to +10 dBm
0.3 to 27, 40, 46
or 60 GHz dep. on model
0.01 dBm @100 ms measuring
time
±1 dBm typ. to 27 GHz
±2 dBm typ. to 40 GHz
±3 dBm typ. to 60 GHz
Auto or Manual
(within ±40 MHz)
20 to 30 ms in Auto (typ.)
Frequency C
Specifications
USER MANUAL ● CNT 9x Series ● Rev.22 February 2020
8-18
