Penn A5 Series User Manual

32
Setting up the refrigeration setup screens
To set up the refrigeration setup parameters, navigate to the REFRIGERATION SETUP start screen, and press
SET. To move through the REFRIGERATION SETUP screens, press the DOWN and UP arrow keys.
To set the setpoint, select the setpoint value from the range -40°F to
122°F and press SET.
To set the system differential, select the differential value from the range
1°F to 15°F and press SET.
To set the failure mode for Sn1, select ON, OFF, or AVG (average), and
press SET.
To set the ASD time for the compressor, select the delay time from the
range 0 minutes to 12 minutes and press SET.
To set the speed of the evaporator fan when the compressor cycles off,
select OFF or HIGH and press SET. Note: The fan speed selection
depends on the selection for EVAP FAN TYPE in the SYSTEM SETUP
screens.
15°FA52x
SETPOINT
SET
SN1: FAILURE
MODE
SET
ANTI-SHORT
CYCLE DELAY
SET
ANTI-SHORT
CYCLE DELAY
1 MIN
SN1: FAILURE
MODE
ON
SETPOINT
35°
EVAP FAN SPEED
COMP OFF
OFF
SET
F
10°
SET
SET
SET
SET
SET
EVAP FAN SPEED
COMP OFF
SET
REFRIGERATION
SETUP
SET
DIFFERENTIAL
SET
DIFFERENTIAL
3°
SET
122
-40
15
1
