Penn A5 Series User Manual

56
Electrical ratings
Table 17 through Table 21 provides the electrical ratings for the control relays in the A5xx Controller. See Table 21
for the relay duty cycle ratings.
Table 17: SPST compressor relay electrical ratings
cULus CE
Applied AC voltage
at 50/60 Hz
24 VAC 120 VAC 240 VAC 240 VAC
Horsepower n/a 1 hp 1 hp 1 hp
Full load amperes n/a 16 A 8 A 8 A
Locked rotor amperes n/a 96 A 48 A 48 A
Resistive amperes 10 A
Pilot duty VA 125 VA at 24 VAC to 240 VAC
Table 18: SPDT alarm relay electrical ratings
cULus CE
Applied AC voltage
at 50/60 Hz
24 VAC 120 VAC 240 VAC 240 VAC
Horsepower
(LC/LNO and LC/LNC)
n/a 1/2 hp 1/2 hp 1/2 hp
Full load amperes
(LC/LNO and LC/LNC)
n/a 9.8 A 4.9 A 4.9 A
Locked rotor amperes
(LC/LNO and LC/LNC)
n/a 58.8 A 29.4 A 29.4 A
Resistive amperes
(LC/LNO and LC/LNC)
10 A
Pilot duty VA
(LC/LNO and LC/LNC)
125 VA at 24 VAC to 240 VAC
Table 19: SPST lo-spd aux fan relay electrical ratings
1
cULus CE
Applied AC voltage
at 50/60 Hz
24 VAC 120 VAC 240 VAC 240 VAC
Horsepower n/a 1/2 hp 1/2 hp 1/2 hp
Full load amperes n/a 9.8 A 4.9 A 4.9 A
Locked rotor amperes n/a 58.8 A 29.4 A 29.4 A
Resistive amperes 10 A
Pilot duty VA 125 VA at 24 VAC to 240 VAC
Table 20: SPST high-speed fan (HI-SPD) relay electrical ratings
cULus CE
Applied AC voltage
at 50/60 Hz
24 VAC 120 VAC 240 VAC 240 VAC
Horsepower n/a 1/2 hp 1/2 hp 1/2 hp
Full load amperes n/a 9.8 A 4.9 A 4.9 A
Locked rotor amperes n/a 58.8 A 29.4 A 29.4 A
Resistive amperes 10 A
Pilot duty VA 125 VA at 24 VAC to 240 VAC
