Table 21: UL conformity declaration information
Information Description
Purpose of control Sensing control/operating control
Construction of control Electronic independently mounted control
Number of cycles Compressor relay: 100,000
Defrost relay: 30,000
Evaporator fan relays: 30,000
Alarm relay: 8,000
Method of mounting control Four mounting screws or optional DIN rail mounting kit
Type 1C or type 2C action Micro-interruption
Heat and fire resistance category D
Rated impulse voltage 4,000 V
Ball pressure temperature 125°C (257°F)
Cover screw torque
requirements instruction
All models: To maintain the A5xx type IP65 rating, tighten enclosure screws to
0.9 to 1.1 N·m (8 to 10 in·lb).
Table 19: A99B type positive temperature coefficient (PTC) temperature sensor
Ambient sensing and
operating conditions
1
1. When you connect any A99B series temperature sensor to an A5xx Controller, the range of displayed temperature values
is restricted from -40C° to 50Cº (-40F° to 122Fº).
Type A99BA: -40°C to 100°C (-40°F to 212°F); 0% to 100% RH, condensing
Type A99BB: -40°C to 100°C (-40°F to 212°F); 0% to 100% RH, condensing
Type A99BC: -40°C to 120°C (-40°F to 248°F); 0% to 100% RH, condensing
Reference resistance 1,035 ohms at 25°C (77°F) and 855 ohms at 0°C (32°F)
Accuracy 0.5C° (0.9F°) between -15°C and 75°C (5°F and 167°F). Refer to the A99B Series Temperature
Sensors Product/Technical Bulletin (LIT-125186) for accuracy rating outside of this temperature
range.
Sensor construction Probe: stainless steel (50 mm x 6.0 mm)
Cable length: A99Bx-200 (2 m); A99Bx-300 (3 m); A99Bx-500 (5 m)
Sensor cable sheath Type A99BA: Shielded polyvinyl chloride (PVC) cable
Type A99BB: PVC cable
Type A99BC: High temperature silicon cable
Wire gauge
22 AWG (0.33 mm
2
)
Ambient storage
conditions
Type A99BA: -40°C to 105°C (-40°F to 221°F); 0% to 100% RH, condensing
Type A99BB: -40°C to 105°C (-40°F to 221°F); 0% to 100% RH, condensing
Type A99BC: -40°C to 130°C (-40°F to 266°F); 0% to 100% RH, condensing
Shipping weight 41 g (1.4 oz) for 2 m (6.5 ft) sensor
Table 20: TS6340K-F00 negative temperature coefficient (NTC) temperature sensor
Ambient sensing and
operating conditions
-40°C to 100°C (-40°F to 212°F); 0% to 100% RH, condensing
Reference resistance 10,000 ohms at 25°C (77°F)
Sensor construction Probe: stainless steel (50 mm x 6.0 mm)
Cable length: 1.5 m
Sensor cable sheath PVC cable
