INTELLICHEM
®
Controller Installation and User’s Guide
42
IntelliChlor
®
Salt Chlorine
Generator(SCG) Transformer
Load Center (with SCG option)
Power Center
(with SCG option)
CONNECT INTELLICHEM CONTROLLER
AC POWER TO FILTER PUMP RELAY
CONNECT INTELLICHEM CONTROLLER
AC POWER TO FILTER PUMP RELAY
Retaining
screws
High Voltage
Front Panel
Route IntelliChem
®
Controller AC
power into opening under enclosure
