240
Using the Flash
9
You can use the P-TTL auto flash with an AF540FGZ, AF360FGZ,
AF200FG or AF160FC flash unit.
1
Remove the cover of the hot shoe, and attach the external
flash.
2
Turn on the camera and the external flash.
3
Set the external flash mode to [P-TTL].
4
Make sure that the external flash is fully charged, and then
take a picture.
The b will light in the viewfinder or Live View screen when the flash is
ready (fully charged).
Using the P-TTL Auto Flash
• For details such as operation method and effective distance, refer to the
external flash manual.
• Never press the E button when any external flash unit is attached to the
camera. The built-in flash will hit the external flash. If you want to use both at
once, set the wireless mode or connect them using the extension cord.
(p.244)
e_kb524_84percent.book Page 240 Friday, June 15, 2012 12:13 PM
