Pentax K-30 User Manual

52
Getting Started
2
Attaching a Lens
Attach a proper lens to the camera body.
When you use one of the following lenses with this camera, all the
camera’s capture modes are available.
(a) DA, DA L, D FA, FA J lenses
(b) Lenses with an s (Auto) position; when used in the s position
1 Make sure that the camera is turned off.
2 Remove the body mount cover
(
1 ) and lens mount cover ( 2 ).
Be sure to put the lens down with the lens
mount side facing upward to protect the
lens mount from damage when there is
no lens mount cover on the lens.
• When attaching or removing a lens, choose an environment that is relatively
free of dirt and dust.
• Keep the body mount cover on the camera when a lens is not attached.
• Be sure to attach the lens mount cover and lens cap to the lens after
removing the lens from the camera.
• Do not insert any fingers into the camera mount or touch the mirror.
• The camera body and lens mount incorporate lens information contacts. Dirt,
dust, or corrosion on the contacts may damage the electrical system. Please
contact a PENTAX Service Center for professional cleaning.
• Some functions will be restricted when one of lenses described in (b) is used
with the aperture ring set to the position other than s, or when a lens other
than listed above and/or other accessories are used. Refer to “Functions
Available with Various Lens Combinations” (p.255) for details.
• If a lens for which the focal length information cannot be automatically
obtained is used, the [Input Focal Length] screen appears when the camera
is turned on. Refer to “Setting the Focal Length” (p.258) for details.
• We assume no responsibility nor liability for accidents, damages and
malfunctions resulting from the use of lenses made by other manufacturers.
e_kb524_84percent.book Page 52 Friday, June 15, 2012 12:13 PM

Pentax K-30 Specifications

General

Megapixel	16.28 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	Yes
Total megapixels	16.49 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	4928 x 3264 pixels
Image sensor size (W x H)	23.7 x 15.7 mm
Still image resolution(s)	16M (4928 x 3264 pixels), \\r 10M (3936 x 2624 pixels), \\r 6M (3072 x 2048 pixels), \\r 2M (1728 x 1152 pixels)
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Pentax KAF2
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	11
Auto focusing (AF) modes	Continuous Auto Focus, Selective Auto Focus, Single Auto Focus, Spot Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/6000 s
Slowest camera shutter speed	30 s
Flash modes	Red-eye reduction, Second curtain synchro, Slow synchronization
Flash exposure correction	-2EV - +1EV (1/2 EV step)
Power source type	Battery
Video resolutions	640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	AVI, H.264, MPEG4
Maximum video resolution	1920 x 1080 pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.92 x
Viewfinder type	Optical
USB version	2.0
Product color	Blue
Scene modes	Backlight, Beach, Candlelight, Children, Museum, Night, Night portrait, Pet, Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Black&White, Muted, Negative film
White balance	Auto, Cloudy, Custom modes, Daylight, Fine, Flash, Fluorescent, Fluorescent L, Manual, Shade, Tungsten
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Single image, Slide show, Thumbnails
Self-timer delay	2, 12 s
Camera file system	DCF 2.0, Exif 2.3, RAW
Playback zoom (max)	16 x
Diopter adjustment (D-D)	-2.5 - 1.5
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, POL, POR, RUS, SWE, TUR
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery type	D-LI 109
Battery life (CIPA standard)	480 shots
Cables included	AC, USB
Bundled software	PENTAX Digital Camera Utility 4

Weight and Dimensions

Depth	71.5 mm
Width	128.5 mm
Height	96.5 mm
Weight	590 g
Weight (including battery)	650 g
