1.2 Keyboard
W-1502N series is equipped with two color touch screens and alphanumeric
keypad, operation by both touching screen and pressing keyboard is
possible.
Do not touch the screen with ball-pen, pencil or other sharp thing to avoid
damage on instrument.
Keys Name Functions
0~9/ A~! Alphanumeric
keypad
Enter text and numerical values.
α
Shift key for
character entry
The current entry method can shift
among number, smaller letter and
capital letter.
★
Star key Normal configurations can be set
here
Tab Tab key Move the cursor right or next
position
BS BackSpace key Move the cursor left and delete one
character
Ctrl Ctrl key Same with the Ctrl key of PC
Space Space key Enter the space
Enter Enter key Confirm an entry or selection
ESC Escape key Quit a screen or edit mode without
saving changes. Return next higher
level
FUNC Function key Perform variable functions defined
