Pentax W-1502N Series User Manual

29
②
Click “S.Angle” key,
and a dialog box will be
ejected, as is showed in
the right figure.
③
Input horizontal angle
you need.
※
1
Such as
：
232°26'26"
【
S.Angle
】
input
horizontal
angle
④With data entry
complete ，click “Enter”
key,and angle
measurement after
orientation will go on.
【Enter】
※
1 Data entry should be refered to the format shown in the dialog box.
4.3.5 Setting “vertical angle and percent grade” mode with the
“V/%” key
Make sure the operation is under angle measurement mode.
Operation steps Keys Display
