40
①
Click “Setout” key
under distance
measurement mode.
【
Setout
】
②Select distance
measurement mode
(SD,HD,VD)to be set out,
input required data and
then click “Enter” key.
※1
③
Start setting out.
※1 First of all,a prompt that reminds you to input SD to be set out is displayed
in the popup dialog box. Click “Enter” key to execute SD setting out after
inputing data。If you want HD setting out,need to input zero in “SD dialog box”,
click “Enter”,and the system will eject “HD dialog box” automatically. HD
setting out can go on after HD data entry. If you want VD setting out,need to
input zero in both “SD dialog box” and “HD dialog box”, thus the system will
remind you to input elevation difference to be set out.
