44
Operation steps Keys Display
①
Select “None PH”
button with stylus.
【
None PH
】
②
Collimate the ground
point.
③
Click “M.Dist” key to
start observing.
④
Horizontal distance
between instrument and
prism will be shown.
Collimate
prism
【
M.Dist
】
⑤
Click “Continue” key,
andpositionofground
point G is locked that
means reference point is
confirmed.
【
Continue
】
