Pentax W-1502N Series User Manual

62
⑥
Click “Save” key.
Coordinate of P1 can
be ascertained and it
will return main
menu.At last power off
and transfer instrument
to P1(transfer prism
from P1 to P0
meantime).
【
Save
】
⑦After instrument is
established in P1,enter
into traverse surveying
of coordinate
measurement and select
“Call” button with
stylus.
※1)
⑧
Collimate last
occupied point P0. Click
“Setup” key, then
coordinate of P1 and
azimuth angle from P1
to P0 will be
ascertained. And it
returnstomainmenuat
the same time.
⑨
Repeat steps
①～⑧，
and carry on according
to the sequence of
guidelines till the end.
※
1) Click “Exit” key to finish Traverse Surveying.
