VMP2 PMC-HDD1 Module (Optional)
ID 24855, Rev. 02 © 2002 PEP Modular Computers GmbH Page G - 5
Table G-2: IDE Hard Disk Drive Connector Pinout
Pin Number Signal Function In/Out
1 IDERESET Reset HD Out
2
GND Ground signal --
3 HD7 HD data 7 In/Out
4 HD8 HD data 8 In/Out
5 HD6 HD data 6 In/Out
6 HD9 HD data 9 In/Out
7 HD5 HD data 5 In/Out
8 HD10 HD data 10 In/Out
9 HD4 HD data 4 In/Out
10 HD11 HD data 11 In/Out
11 HD3 HD data 3 In/Out
12 HD12 HD data 12 In/Out
13 HD2 HD data 2 In/Out
14 HD13 HD data 13 In/Out
15 HD1 HD data 1 In/Out
16 HD14 HD data 14 In/Out
17 HD0 HD data 0 In/Out
18 HD15 HD data 15 In/Out
19
GND Ground signal --
20 N/C -- --
21 IDEDRQ DMA request In
22
GND Ground signal --
23 IOW I/O write Out
24
GND Ground signal --
25 IOR I/O read Out
26
GND Ground signal --
27 IOCHRDY I/O channel ready In
28
GND Ground signal --
29 IDEDACKA DMA Ack Out
30
GND Ground signal --
31 IDEIRQ Interrupt request In
32 N/C -- --
33 A1 Address 1 Out
34 N/C -- --
35 A0 Address 0 Out
36 A2 Address 2 Out
37 HCS0 HD select 0 Out
38 HCS1 HD select 1 Out
39 NC -- In
40
GND Ground signal --
41
VCC 5V power --
42
VCC 5V power --
43
GND Ground signal --
44
N/C -- --
