PMC-HDD1 Module (Optional) VMP2
Page G - 4 © 2002 PEP Modular Computers GmbH ID 24855, Rev. 02
Table G-1: Pinout of the PMC Connectors
.
PN1/JN1 (CON1) PN2/JN2 (CON2)
Pin # Signal Name Signal Name Pin # Pin # Signal Name Signal Name Pin #
1 Signal -12V 2 1 +12V Signal 2
3 Ground Signal 4 3 Signal Signal 4
5 Signal Signal 6 5 Signal Ground 6
7 BUSMODE1# +5V 8 7 Ground Signal 8
9 Signal Signal 10 9 Signal Signal 10
11 Ground Signal 12 11 BUSMODE2# +3.3V 12
13 Signal Ground 14 13 Signal BUSMODE3# 14
15 Ground Signal 16 15 +3.3V BUSMODE4# 16
17 Signal +5V 18 17 Signal Ground 18
19 V (I/O) Signal 20 19 Signal Signal 20
21 Signal Signal 22 21 Ground Signal 22
23 Signal Ground 24 23 Signal +3.3V 24
25 Ground Signal 26 25 Signal Signal 26
27 Signal Signal 28 27 +3.3V Signal 28
29 Signal +5V 30 29 Signal Ground 30
31 V (I/O) Signal 32 31 Signal Signal 32
33 Signal Ground 34 33 Ground Signal 34
35 Ground Signal 36 35 Signal +3.3V 36
37 Signal +5V 38 37 Ground Signal 38
39 Ground Signal 40 39 Signal Ground 40
41 Signal Signal 42 41 +3.3V Signal 42
43 Signal Ground 44 43 Signal Ground 44
45 V (I/O) Signal 46 45 Signal Signal 46
47 Signal Signal 48 47 Ground Signal 48
49 Signal +5V 50 49 Signal +3.3V 50
51 Ground Signal 52 51 Signal Signal 52
53 Signal Signal 54 53 +3.3V Signal 54
55 Signal Ground 56 55 Signal Ground 56
57 V (I/O) Signal 58 57 Signal Signal 58
59 Signal Signal 60 59 Ground Signal 60
61 Signal +5V 62 61 Signal +3.3V 62
63 Ground Signal 64 63 Ground Signal 64
