6000 Series Purge/Pressurization System
I/O Manual
The EPV-6000 vent
is required.
6000 Control Unit
Vent
Mounts on vertical or horizontal
surface of the enclosure
Rotating vent cap
Spark arrestor
M12 (V1) connector
for I.S. connection
to control unit
Seal washer
Lock nut
Temperature
monitoring/control
accessories
I.S.
temperature
sensor
1.5 " NPT knockout
(Ø 2", 50.8 mm)
Manifold
Manifold for
purging and
pressurization
Needle valve for
pressurization of enclosure
(requires athead
screwdriver for adjustment)
Connection to
protective gas
supply
Manifold with
I.S. solenoid
valve
Type 4X (IP66)
ttings for
enclosure ow
I.S. temperature hub
Conduit plug
