6000 Series Purge/Pressurization System
I/O Manual
83.0 mm
(3.25'')
20.5 mm
(0.80'')
58,7 mm
(2.31'')
124.0 mm
(4.90'')
27.0 mm
(1.05'')
30 mm
(1.20'')
35.5 mm
(1.40'')
62.0 mm
(2.45'')
13.5 mm
(0.55'')
124.0 mm
(4.90'')
#8-32 thread
mounting
location x 2
Grounding lug
(included)
Note
Warning
UIC for the component kit
The user interface can be mounted either
inside or outside the pressurized enclosure
using the dimensions in the two previous
drawings above.
Do not make the opening any larger than
indicated in the cutout. Install with the gasket
provided (panel mount only).
6000-TEMP-01, temperature hub
-
SIG
-
NC
SIG
NC
+
+
SIG
-
B
V+
A
V-
SENSOR 3
SENSOR 1
SENSOR 2
Twinsburg, OH 44087 USA/www.pepperl-fuchs.com
SYSTEM CONNECTIONS
NC
+
6000-TMP-01
PartNo. 514202
6000X-PURGE TEMPERATURE HUB
POWER
FAULT
94.0 mm
(3.70")
21.5 mm
(.85")
52.0 mm
(2.05")
35 mm DIN rail or
panel mounted
