6000 Series Purge/Pressurization System
I/O Manual
Programming worksheet
SETUP - PASSWORD - PURGE SETTINGS -
ENCLOSURE VOLUME
(XXXX FT3 [M3])
- USER DEFINED -
-
# OF EXCHANGES
(5).
- 4 - 19 -
-
PURGE FLOW
(12)
- 5 (141 L/M)
- 12 (340 L/M)
- 20 (565 L/M)
- 30 850 L/M)
- DYNAMIC
-
VENT FLOW
CONTROL
(ONE VENT)
- ONE VENT
-
2 VENTS ADD
FLOWS
-
2 VENTS LEAST
FLOW
- 2 VENTS SIL
-
ENVIRONMENT
(GAS)
- GAS, DUST, BOTH -
- PRESSURES -
MAX OVER
PRESSURE
(4.0 IN WC [10
MBAR])
-
-
LOW PRESSURE
(4.0 IN WC [10
MBAR])
-
-
MIN OVER
PRESSURE
(0.25 IN WC [0.63
MBAR])
-
- TIMERS - PURGE TIMER -
READ ONLY -
FIXED TIME
-
SHUTDOWN TIMER
(0 SEC.)
- 0 - 300 SEC. -
-
UNLOCK DOOR
TIMER
(0 MIN)
- 0 - 300 MIN. -
-
OPERATION MODE
(FA)
- STD, SA, FA -
-
UNITS
(ENGLISH)
- ENGLISH
- METRIC
